Reaction Vessel
Precision-engineered reaction vessels designed for efficient chemical processing, mixing, and thermal applications. Manufactured using corrosion-resistant FRP and thermoplastic materials, our vessels ensure durability, safety, and reliable performance in demanding industrial environments.
Nivra Envirotech Pvt. Ltd. manufactures high-performance Reaction Vessels specially engineered for chemical processing, thermal operations, mixing applications, and industrial reactions. Designed using advanced FRP and thermoplastic materials, our vessels offer superior corrosion resistance, structural durability, leak-proof operation, and long-term reliability in demanding industrial environments.
Our Reaction Vessels are suitable for handling aggressive chemicals, high-temperature applications, and complex industrial processes across chemical, pharmaceutical, agrochemical, wastewater treatment, and metal processing industries. With advanced engineering capabilities and precision manufacturing, we deliver customized solutions tailored to specific operational requirements.
Types of Reaction Vessels
- Flat Bottom Cylindrical Reactor
- Conical Bottom Reactor
- Sloped Bottom Reactor
- Dish-End Bottom Reactor
- Open-Top Reactors
Optional accessories include sight glass, baffles, temperature ports, spray balls, sampling valves, and vapor recovery ports.
Agitation & Mixing Systems
Our Reaction Vessels can be equipped with top-mounted or side-mounted agitator systems designed according to process requirements, viscosity, reaction kinetics, and mixing intensity.
Stirrer Designs Available:
- Anchor Stirrer
- Pitched Blade Turbine
- Propeller Stirrer
- Helical Ribbon Agitator
We also provide TEFC and Flameproof motor options with inline or parallel shaft helical gear reducers for efficient operation.
Technical Specifications
| Parameter | Specification |
|---|---|
| Design Pressure | Vacuum to 10 Bar |
| Design Temperature | Up to 80°C (Thermoplastics), 210°C (FRP) |
| Capacity Range | 100 L to 100,000+ L |
| Diameter Range | 300 mm to 4000 mm+ |
| Orientation | Vertical / Horizontal |
| Support Type | Skirt, Legs, Saddle |
| Corrosion Protection | Built-in via liner thickness & safety factor |
| Design Standard | ASME RTP-1, BS EN 13121, ASTM D3299 / D4097, ISO 14692 |
| Material of Construction | Thermoplastic (PP, PPH, HDPE, C-PVC, PVDF, TFM, FEP, PFA, ECTFE) |
Industries & Applications
Our Reaction Vessels are widely used in chemical processing industries, pharmaceutical manufacturing units, petrochemical plants, agrochemical industries, wastewater treatment facilities, textile and dye industries, and specialty chemical production plants. These vessels are ideal for chemical mixing, blending, thermal processing, batch reactions, dosing applications, and process manufacturing operations.
Designed for harsh industrial conditions, our Reaction Vessels support efficient process control, safe chemical handling, and reliable production performance while maintaining high durability and corrosion resistance.
Frequently Asked Questions (FAQ)
Our Reaction Vessels are manufactured using premium FRP and thermoplastic materials such as PP, PPH, HDPE, PVC, CPVC, and PVDF based on process requirements.
Yes, our vessels are specifically engineered for handling corrosive chemicals and demanding industrial processes with excellent corrosion resistance.
Yes, we provide fully customized Reaction Vessels in different capacities, shapes, thicknesses, and configurations according to industrial requirements.
Our Reaction Vessels are widely used in chemical, pharmaceutical, petrochemical, agrochemical, textile, and wastewater treatment industries.
Yes, we offer complete technical assistance including consultation, installation guidance, and after-sales support for all our products.
Export Markets
Nivra Envirotech Pvt. Ltd. proudly supplies and exports Reaction Vessels to various international markets across the Middle East and African regions. Our export network includes countries such as UAE, Saudi Arabia, Oman, Qatar, Kuwait, Bahrain, South Africa, Kenya, Nigeria, Tanzania, Egypt, and Ghana.
With a strong commitment to engineering excellence and product quality, we continue to deliver reliable industrial solutions to clients worldwide.
Looking for High-Performance Reaction Vessels?
Partner with Nivra Envirotech Pvt. Ltd. for durable, corrosion-resistant, and customized Reaction Vessels engineered for reliable industrial processing and long-term operational performance. Contact us today for expert consultation and customized quotations.
